PCB Express Service

PCB Express Service

LeitOn´s PCB express service provides you with industral production of circuit boards starting at 2 hours. Conditions for our PCB express service are as follows.

1-layer PCB LeitOn Express service starting at 4 hours:

  • Standard material FR4
  • 1-layer layout
  • 6mil-technology (0,15mm clearance and circuit path)
  • maximum board size 200 x 360 mm²
  • Without solder resist
  • Without electric testing
  • Without silk print
  • Standard outline (quadrangular circuit board)
  • Maximum of 1000 drills per board

Time of delivery for our circuit board express service begins after clarification of all technical details and data delivery between 07:00 am and 02:00 pm during normal working days. Depending on location, delivery can be carried out by messenger or UPS Express.

2-layer PCB LeitOn Express service starting at 6 hours:

  • Standard FR4 material
  • 2-layer layout
  • Through hole plated PCB
  • 6mil-technology (0,15mm circuit path and clearance)
  • Maximum circuit board size 200 x 360 mm²
  • Including solder resist
  • Including electric testing
  • Without silk print
  • Standard routing shape (quadrangular circuit board)
  • Maximum of 1000 drills per board

Time of delivery for the 2-layer printed circuit board express service begins after clarification of all technical details and data delivery between 07:00 am and 12:00 pm during normal working days. Depending on location delivery can be carried out by messenger or UPS Express.

Please note that advanced notification by phone and capacity check is necessary, to ensure a smooth PCB Express service.
